Extreme Environment Gauge

Specifications

Salamander P1

MAX TEMP C° [F°]: 205° [401°]
MIN TEMP C° [F°]: 65° [149°]
MAX DURATION @C: >60d
PRESSURE RANGES: 20k, 25k, 30k
PRESSURE ACCURACY: +/- 0.025% of Full scale
PRESSURE RESOLUTION: 0.001psi (1sec sampling)

SALAMANDER P2 (Q1 2016)

MAX TEMP C° [F°]: 225° [437°]
MIN TEMP C° [F°]: 65° [149°]
MAX DURATION @C: TBD
PRESSURE RANGES: 20k, 25k, 30k
PRESSURE ACCURACY: +/- 0.025% of Full scale
PRESSURE RESOLUTION: 0.001psi (1sec sampling)


Applications

  • Extreme downhole environment pressure temperature collection

Features

  • Thirty years of HP/HT experience
  • Robust and accurate quartz memory gauge

Benefits

  • High reliability
