Wireless Thermal Imaging

A method of mapping the flowing temperature profile of a zone.

Specifications

-20°C to 150°C (302°F)

temperature range

up to 2 million

memory capacity

30 days to multi-year (10 years, battery pack + temperature dependent)

DURATION

0.004°C

resolution

18,000psi - 25,000psi

PRESSURE RATING

1/4″ (3/8″ for perforating guns)

sensor TUBING DIAMETER

Applications

  • TCP gun fire and performance verification
  • Flow allocation during DST
  • Cross flow detection and monitoring, especially during build-ups
  • Production and injection profiles for completed wells
  • Frac performance observation/gravel pack deployment

Features

  • Wireless system with no wellhead of packer penetrations
  • Deployable on perforating guns
  • Autonomous tools permit tool redundancy at each location
  • Duplex communication for data collection from multiple devices

Benefits

  • Reservoir profiling below obstructions such as an artificial lift pumps
  • Continuous flow profiling throughout operation
  • Combinable with FLOW-SURE devices to manage your well
  • Deployable beneath permanent packers without failure prone wet-connects
